| Year | 2000 |
|---|---|
| Make | Star |
| Model | SA-12 |
Description |
CNC Swiss Lathe |
| Reference # | 8071627 |
|
This machine has been recently sold. If you are interested in a similar machine, We will be happy to locate one for you. |
|
Used Star SA-12 (2000) CNC Swiss Lathe for Sale. This pre-owned Star CNC swiss lathe is located in The United States and available to be seen under power for an inspection. If you have any questions regarding this Star Swiss Lathe, please feel free to contact us. You may Activate Pricing to view the price of this CNC Machine, or request a quote by clicking on the Inquire Now button.
Specifications
| Bar Capacity |
0.5" |
|---|---|
| Swing |
10" |
| Turning Diameter |
0.625" |
| Spindle Speed |
Up To 12,000 RPM |
| Turning Length (Max) |
5.310" |
| Main Spindle |
5 HP |
| Index Increment |
1 Degree |
| Max Tools Turning (Primary Carrier) |
6 |
| Tool Shank Size (Primary) |
Square - 0.393” |
| Max Tools Turning (Second Carrier) |
2 |
| Tool Shank Size (Second) |
Square: 0.393" Rotary: 0.500" |
| Rotary Tools (Second Carrier) |
2 |
| Max Tools Turning (Third Carrier) |
4 |
| Tool Shank Size (Third) |
Square: 0.393" Rotary: 0.500" |
| Rotary Tools (Third Carrier) |
4 |
| Rotary Tool Spindle |
8,000 RPM |
| Rotary Tool Power |
1 HP |
| Number of Axes: Standard |
5 |
| Simultaneous Cutting Tools |
3 |
| Rapid Rate |
X - 708 IPM Y1 - 708 IPM |
| Machine Dimensions |
82”L x 30”W x 65”H |
| Machine Weight |
3,740 Lbs |
Features
|
Secondary Mill/Drill Function |
Slide Primary/Second/Third Carrier Type |
|
Standard Sub-Spindle |
