| Year | 2008 |
|---|---|
| Make | Mag Plastics |
| Model | SSB-02 |
Description |
Blow Molder |
| Reference # | 8072667 |
Price |
Activate PricingInquire Now |
Used Mag Plastics SSB-02 (2008) Blow Molders for Sale. This pre-owned Mag Plastics blow molding machine is located in The United States and available to be seen under power for an inspection. If you have any questions regarding this Mag Plastics Blow Molder, please feel free to contact us. You may Activate Pricing to view the price of this Plastic Molding Machine, or request a quote by clicking on the Inquire Now button.
Specifications
| Press Closing Force |
220 kN |
|---|---|
| Preform Support Ring Dia. (max.) |
52 mm |
| Preform Neck Dia. (min. int./max. ext.) |
14 mm / 45 mm |
| Preform Length |
70 - 180 mm |
| Number of Heater Zones |
9 / 1500W per lamp |
| Number of Heater Boxes |
2 |
| Number of Cavities |
2 |
| Nominal Output (2-cavity) |
2800 bottle/hour |
| Heating Power |
27 kW |
| Bottle Size Ranges |
.2 L to 2.25 L |
| Bottle Height (max) |
350 mm |
| Bottle Diameter (max) |
115 mm |
| Note |
(2) Two Machines (2008 & 2010) Available, Price per Machine |
*
Important: All machinery specifications must be independently verified by buyer. All machinery sales are
subject to prior sale. Any agreement to purchase or sell machinery must be in writing.
