Year 2011
Make Omax
Model 55100

Description

4.6' x 8.4' CNC Waterjet
Reference # 8072246

Price

Activate PricingInquire Now

Used Omax 55100 (2011) CNC Waterjet for Sale.  This pre-owned Omax CNC waterjet is located in Oregon.  If you have any questions regarding this Omax Waterjet, please feel free to contact us.  You may Activate Pricing to view the price of this CNC Machine, or request a quote by clicking on the Inquire Now button.

Specifications

Table Width

4.6'

Table Length

8.4'

Control

Intellimax

Pump

40 HP

Max Cutting Pressure

55,000 PSI

Power Requirement

460/3/60

Table Size

125" X 65"

Over One Foot Travel

+/-0.003” 0.08 mm

Repeatability

+/-0.002” 0.051 mm

Squareness

0.002” per foot 0.17 mm/m

Straightness

0.003” per foot 0.25 mm/m

Backlash

0.0007” max. 0.018 mm

Note

Machine Available Febuary of 2023

Features

600 lb Abrasive Delivery System

Digital Drives

OMAX Patented Motion Control Software Incorporating Windows XP Software

Optimal Stack Height Calculator - Maximizes Your Machine Time by Stacking Materials

Pre-Loaded Ballscrews with Recirculating Ball Bearings and Hardened Precision Ground Ways

Brushless Servo Motors

EBBCO Garnet Removal System

* Important: All machinery specifications must be independently verified by buyer. All machinery sales are subject to prior sale. Any agreement to purchase or sell machinery must be in writing.
